Shooting modes
Nine preset shooting modes ensure ease and reliability of use.
-
Standard - Standard intraoral photography with true-colour optimisation
-
Surgery - Intraoral photography from a greater distance
-
Mirror - Intraoral photography using a dental mirror. The image can be reversed afterwards
-
Face - Facial photographs, half-body or full-body portraits
-
Low Glare - Photographing details of anterior teeth, working models or indirect restorations outside the patient´s mouth
-
Whitening - Comparison of tooth shades before and after whitening / bleaching
-
Tele macro -Detailed close-ups of anterior teeth with the close-up lens attached
-
Isolate Shade - Automatic isolation of the gingival shade for optimal shade taking
-
Movie - Permanent autofocus during filming enables consistently sharp videos
Exemplary hygiene
The completely smooth body of the EyeSpecial C-V is water and chemical-resistant and can be quickly and thoroughly disinfected with ethanol sprays and wipes.
Glare-free to show more of the tooth with the cross polarizer
With the cross polarizer attached, the EyeSpecial C-V allows you to look inside a tooth: Chroma, internal light effects and individual tooth characteristics are visualised without being distorted by light reflections occurring on the enamel surface. Shade and colour effects of hard and soft tissues can also be assessed more accurately when using the cross polarizer.
The cross polarizer is designed in such a way that the polarizing components are positioned at right angles to the flash and lens part, eliminating any reflections on the tooth surface.
-
Without cross polarizer
-
With cross polarizer
-
Digital documentation with the SHOFU Gumy-V
The EyeSpecial C-V dental camera features a special “Isolate Shade” mode for photo documentation with and without the gingiva. In this mode, up to three images are taken, showing
- the situation in true colours
- the situation with automatic masking of the gingival area
- the situation in black and white to assess the brightness.
Photographic comparison of the natural tooth shade with the gingiva-coloured SHOFU Gumy-V shade tab holder and the corresponding colour tabs provides important additional details.
-
Isolate Shade - in true colours
-
Isolate Shade - masking of the gingival area
-
Isolate Shade - in black and white
The delivery includes
- the camera EyeSpecial C-V
- Close-up lens (49 mm) from Kenko
- Lens cap
- Hand strap
- 16 GB SDHC memory card
- SHOFU gray card
- User manual
- Quick reference
- Important safety instructions
EyeSpecial C-V dental camera in use
Product details
Downloads
Here you can download product-relevant documents as PDF files.
Important software information for download
WLSDMonitor
The receiving software WLSDMonitor is required to automatically transfer the images saved on the SD card to your computer using the Wi-Fi function of the EyeSpecial C-V camera. It is only available in English. WLSDMonitor receiving software: www.shofu.co.jp/wlsdmonitor/en/
SHOFU SureFile
The SHOFU SureFile software is required to quickly sort and file all images taken by the EyeSpecial C-V according to the patient information entered prior to capturing images. The software is compatible with the models C-II, C-III, C-IV and C-V.
SHOFU SureFile: www.shofu.co.jp/surefile/indexe.html
Firmware (Ver.01.05.00) EyeSpecial C-V: www.shofu.co.jp/eyespecialc5/firmware_en.html
You can find the technical information about the EyeSpecial C-IV in the download area.
